Type: P-Channel
Vdss: 40V
Id: 60A
RDS(on)@Vgs,Id: 7.9mΩ@10V,20A
Vgs(th)@Id: 1.6V@250uA
Pd: 60W
Features
l40V160A,
RDS(ON)=5.1mΩ(typ) @VGS=10V
RDS(ON)=6.2mΩ(typ) @VGS=4.5V
lReliable and Rugged
lLead Free and Green Devices Available(RoHS Compliant)
Applications
lPower Management in Desktop Computer or DC/DC Converters.
| File Name | Title | Description |
|---|---|---|
| SL4184 TO-252.pdf | SL4184 TO-252 | - |
