Type: N-channel
Vdss:650V
Id: 8A
RDS(on)@Vgs,Id: 550mΩ@10V,2.5A
Vgs(th)@Id: 4.5V@250μA
Pd: 69W
Description
lThis Power MOSFET is produced using Slkor's advanced Super junction MOSFET technology. This advanced technology has been especially tailored to minimize on-state resistance, provide superior switching performance, and with stand high energy pulse in the avalanche and commutation mode. These devices are well suited for high efficiency switched mode power supplies.
Features
l8A,650V,RDS(onTyp=550mΩ@VGS=10V
lLow gate charge(typ.Qg=10.1nC)
lHigh ruggedness
lUltra fast switching
l100% avalanche tested
lImproved dv/dt capability
