● Trench Power LV MOSFET technology
● High density cell design for Low RDS(ON)
● High Speed switching
P-Channel Enhancement Mode Field Effect Transistor
Product Summary
● VDS -40V
● ID -4.4A
● RDS(ON)( at VGS=-10V) ＜90mohm
● RDS(ON)( at VGS=-4.5V)＜150mohm
General Description
● Trench Power LV MOSFET technology
● High density cell design for Low RDS(ON)
● High Speed switching
| File Name | Title | Description |
|---|---|---|
| SL2319A SOT-23.pdf | SL2319A SOT-23 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
