Type:N-Channel
Vdss:20V
Id:5A
Pd:1.25W
RDS(on)@Vgs,Id:25mΩ@4.5V,5A
Vgs(th)@Id:1.2V@250μA
General Features
● VDS=20V.Id=5A
RDS(ON)<35mΩ @VGS=2.5V
RDS(ON)<25mΩ @VGS=4.5V
● High power and current handing capability
● Lead free product is acquired
● Surface mount package
Application
● Battery protection
● Load switch
● Power management
| File Name | Title | Description |
|---|---|---|
| SL2312.pdf | SL2312 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
