High power and current handing capability
Lead free product is acquired
Surface mount package
General Features
● VDS=60V.ID=300mA
RDS(ON)<3Ω@VGS=10V
RDS(ON)<3.5Ω@VGS=5V
● High power and current handing capability
● Lead free product is acquired
● Surface mount package
Application
● PWM applications
● Load switch
● Power management
| File Name | Title | Description |
|---|---|---|
| 2N7002E.pdf | 2N7002E | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
