● High power and current handing capability
● Lead free product is acquired
● Surface mount package
MAXIMUM RATINGS
| Characteristic | Symbol | Max | Unit |
| Drain-SourceVoltage | BVDSS | 20 | V |
| Gate-SourceVoltage | VGS | 10 | V |
| DrainCurrent(continuous) | ID | 4 | A |
| DrainCurrent(pulsed) | IDM | 15 | A |
| TotalDeviceDissipation | PD | 1200 | mW |
| TA=25℃ | |||
| Junction | TJ | 150 | ℃ |
| SolderTemperature/SolderTime | T/t | 260/10 | ℃/S |
| StorageTemperature | Tstg | -55to+150 | ℃ |
| File Name | Title | Description |
|---|---|---|
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| REACH.pdf | REACH | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| RoHS-1.pdf | RoHS | - |
| SL2306.pdf | SL2306 | - |
