This diode features a maximum reverse voltage rating of 50V, ensuring reliable performance in a variety of applications. With a low forward voltage drop of 1.3V and a minimal reverse leakage current of just 5μA, it provides optimal efficiency and reduced power loss. The diode is housed in a compact SMBF package, offering versatility and ease of integration into various designs.
Download datasheet Inquiry
OUR ADVANTAGE
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
DESCRIPTION
This diode features a maximum reverse voltage rating of 50V, ensuring reliable performance in a variety of applications. With a low forward voltage drop of 1.3V and a minimal reverse leakage current of just 5μA, it provides optimal efficiency and reduced power loss. The diode is housed in a compact SMBF package, offering versatility and ease of integration into various designs.
FEATURES
● For surface mounted applications
● Low profile package
● Glass Passivated Chip Junction
● Lead free in comply with EU RoHS 2011/65/EU directives
APPLICATIONS
● Power Rectification: Efficiently converts AC to DC in power supply circuits.
● Switching Circuits: Ideal for high-speed switching applications due to its fast reverse recovery time.
● Protective Diodes: Protects sensitive components from voltage spikes and reverse polarity.
● Voltage Clamping: Provides stable voltage regulation in clamping circuits.
