The M7F General Purpose Silicon Rectifiers are high-quality diodes designed for a wide range of electronic applications. Encased in the compact SMAF package, these rectifiers offer reliable performance in various circuits, ensuring optimal efficiency and durability. With a peak reverse voltage of 1000V, a forward current of 1A, and a low forward voltage drop of 1.1V, these diodes are engineered to meet the demands of both commercial and industrial environments.
Download datasheet Inquiry
Surface Mount General Purpose Silicon Rectiflers
Our adventage
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
The M7F General Purpose Silicon Rectifiers are high-quality diodes designed for a wide range of electronic applications. Encased in the compact SMAF package, these rectifiers offer reliable performance in various circuits, ensuring optimal efficiency and durability. With a peak reverse voltage of 1000V, a forward current of 1A, and a low forward voltage drop of 1.1V, these diodes are engineered to meet the demands of both commercial and industrial environments.
Features
● Low coat construction
● Low forward voltage drop
● Low reverse leakage
● High forward surge current capability
● High temperature soldering guaranteed:
260℃/10 secods/.375”(9.5mm)lead length at 5 lbs(2.3kg) tension
Applications
● Power Supplies: Converts AC voltage to DC voltage efficiently in power adapters, chargers, and industrial power supplies.
● Rectification: Provides smooth rectification in welding equipment, power inverters, and battery chargers.
● Voltage Regulation: Ensures stable voltage output in voltage regulator circuits and high-voltage power systems.
