The M7 diode is a high-performance surface-mount general rectifier, known for its efficiency and reliability in various electronic applications. Featuring a forward voltage of 1.1V and a maximum reverse voltage of 1000V, it is designed to handle a wide range of voltage and current requirements.
Download datasheet Inquiry
SURFACE MOUNT GENERAL RECTIFIER
Our adventage
Description
The M7 diode is a high-performance surface-mount general rectifier, known for its efficiency and reliability in various electronic applications. Featuring a forward voltage of 1.1V and a maximum reverse voltage of 1000V, it is designed to handle a wide range of voltage and current requirements.
Features
● Low coat construction.
● Low forward voltage drop.
● Low reverse leakage.
● High forward surge current capability.
● High temperature soldering guaranteed: 260C/10 secods/.375" (9.5mm) lead length at 5 Ibs (2.3kg) tension.
Applications
● Power Supplies: Used for rectification and voltage regulation in various power supply circuits.
● Battery Chargers: Ensures efficient charging by rectifying AC to DC with minimal voltage drop.
● Lighting: Supports LED drivers and other lighting applications where efficiency and reliability are critical.
● Consumer Electronics: Integrated into devices such as TVs, computers, and appliances for power management and protection.
● Industrial Equipment: Used in industrial control systems and automation for reliable operation under varying conditions.
Mechanical Data
● Case: Transfer molded plastic.
● Epoxy: UL94V-O rate flame retardant.
● Polarity: Color band denotes cathode end.
● Lead: Plated axial lead,solderable per MIL-STD-202E method 208C.
● Mounting position: Any.
Maximum Ratings And Electrical Characteristics
● Ratings at 25 C ambient temperature unless otherwise specified.
● Single Phase,.half wave,.60Hz,.resistive or inductive load.
● For capacitive load derate current by 20%.
