The Polar Bidirectional TVS Diode is an advanced electronic component designed to protect sensitive circuits from transient voltage spikes and surges. It features a bidirectional design, ensuring effective clamping of voltage fluctuations in both directions. With robust construction and high reliability, this diode is essential for safeguarding electronic systems against potential damage from unpredictable electrical events.
FEATURES
● Glass Passivated Die Construction
● Uni- and Bi-Directional Versions Available
● Excellent Clamping Capability
● Fast Response Time
● Plastic Case Material has UL Flammability Classification Rating 94V-O
MECHANICAL DATA
● Case : JEDEC SMA(DO-214AC), Transfer Molded Epoxy
● Terminals : Solder Plated, Solderable per MIL-STD-750, Method 2026
● Polarity : Cathode Band Except Bi-Direction+al
Applications
● Telecommunications
● Consumer Electronics
● Automotive Electronics
● Industrial Equipment
| File Name | Title | Description |
|---|---|---|
| SMAJ6.5CA.pdf | SMAJ6.5CA | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
This high-performance TVS (Transient Voltage Suppression) Diode, housed in a compact DO-214AC package, is engineered to provide robust protection for electronic circuits against transient voltage spikes. Designed to handle a maximum working voltage (VRWM) of 12V, it ensures reliable operation and effective suppression of transient surges, safeguarding sensitive components in various applications.
?The Polar Bidirectional TVS Diode is a high-performance semiconductor device designed to protect sensitive electronic circuits from transient voltage events. With its bidirectional clamping capability, it effectively safeguards against both positive and negative voltage spikes, ensuring reliable operation under varying electrical conditions.
The Polar Bidirectional TVS Diode, serving as an alternative to the DIODES SMAJ33CA-13-F, is specifically engineered to protect sensitive electronic circuits from transient voltage spikes. Designed with robust bidirectional clamping capabilities, it ensures reliable operation in environments prone to voltage fluctuations and surge events.
SMAJ7.0CA TVS Diode DO-214AC
SMAJ6.8CA TVS Diode DO-214AC
Vrwm:9.4V VBR(min):10.5V VBR(max):11.6V Ir:5μA VC:15.6V Ppp@10/1000μs:600W
VRWM (max): 13V VBR(min): 14.4V VBR(max): 15.9V IR(max): 5µA VC(max): 21.5V Package: SMA
This high-power TVS (Transient Voltage Suppression) Diode, featuring a color-banded cathode for easy identification, is designed to offer superior protection against transient voltage spikes. With its high breakdown and clamping voltages, this diode is ideal for safeguarding sensitive electronics in demanding applications.
