?The Polar Bidirectional TVS Diode is a high-performance semiconductor device designed to protect sensitive electronic circuits from transient voltage events. With its bidirectional clamping capability, it effectively safeguards against both positive and negative voltage spikes, ensuring reliable operation under varying electrical conditions.
Download datasheet InquiryOur advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
The Polar Bidirectional TVS Diode is a high-performance semiconductor device designed to protect sensitive electronic circuits from transient voltage events. With its bidirectional clamping capability, it effectively safeguards against both positive and negative voltage spikes, ensuring reliable operation under varying electrical conditions.
Features
● Glass Passivated Die Construction
● Uni- and Bi-Directional Versions Available
● Excellent Clamping Capability
● Fast Response Time
● Plastic Case Material has UL Flammability Classification Rating 94V-O
Mechanical Data
● Case : JEDEC SMA(DO-214AC), Transfer Molded Epoxy
● Terminals : Solder Plated, Solderable per MIL-STD-750, Method 2026
● Polarity : Cathode Band Except Bi-Directional
Applications
● Telecommunications
● Industrial Electronics
● Automotive Electronics
● Consumer Electronics
| File Name | Title | Description |
|---|---|---|
| SMF11CA SOD-123FL.PDF | SMF11CA SOD-123FL | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
The PTVSHC2EN5VU is a transient voltage suppressor designed to protect power interfaces. It is suitable to replace multiple discrete components in portable electronics. The PTVSHC2EN5VU is specifically designed to protect power lines. The PTVSHC2EN5VU is available in DFN 1610-2L package. Standard products are Pbfree and Halogen-free.
The Polar Bidirectional TVS Diode is a sophisticated semiconductor device engineered to protect sensitive electronic circuits from transient voltage events in both directions. It acts swiftly to suppress voltage spikes and divert surge currents away from critical components, ensuring the reliability and longevity of electronic systems.
The Polar Unidirectional TVS Diode is an advanced electronic component designed to protect sensitive circuits from transient voltage spikes and surges. With a unidirectional clamping configuration, it effectively suppresses transient voltages exceeding its specified breakdown voltage, safeguarding electronic systems from potential damage. Engineered with precision and reliability, this diode is essential for maintaining the integrity and longevity of electronic devices in various applications.
VRWM (max):5V VBR(min): 5.6V IR(max): 1μA VC(max): 9.5V Cj(max):15pF Package: DFN1006
VRWM (max):36V VBR(min): 40V IR(max): 1μA VC(max): 75V Cj(max):35pF Package: SOD-323
VRWM (max):24V VBR(min): 26.7V IR(max): 1μA VC(max): 52V Cj(max):50pF Package: SOD-323
VRWM (max):8V VBR(min): 8.5V IR(max): 1μA VC(max): 13.4V Cj(max):0.8pF Package: SOD-323
The AZC199-04 has a low capacitance of 0.4pFmaximum and operates with virtually no insertion loss to 1GHz. This makes the device ideal for protection of high-speed data lines such as USB 2.0, Firewire, DVI, and gigabit Ethernet interfaces. The low capacitance array configuration allows the user to protect four high-speed data or transmission lines. The low inductance construction minimizes voltageovershoot during high current surges. They may be used to meet the ESD immunity requirements of IEC61000-4-2, Level 4 (±15kV air, ±8kV contact discharge). This device has been specifically designed to protect sensitive components which are connected to high-speed data and transmission lines from overvoltage caused by ESD (electrostatic discharge), CDE (Cable Discharge Events),and lightning.
