● Fast switching
● Good stability and uniformity with high EAS
● Improved dv/dt capablity
Description
● The Power Device is produced using advanced TRENCH technology.
● This advanced technology has been especially tailored to minimize on-state resistance, provide superior switching perfomance, and with stand high energy pulse in the avalanche and commutation mode.
Features
● Vps=60V，ID=50A
● RDs ( ON )Tp= 14m2 @VGs =10V
● Low gate charge ( typical 33nC)
● High ruggedness
● Fast switching
● Good stability and uniformity with high EAS
● Improved dv/dt capablity
Applications
● DC/DC Converters in Computing, Servers
● Insolated DC/DC Converters in Telecom and Industrial
● Uninterruptible Power Supply
| File Name | Title | Description |
|---|---|---|
| SL50N06D TO-252.pdf | SL50N06D TO-252 | - |
| RoHS-1.pdf | RoHS | - |
| REACH.pdf | REACH | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
