Super high density cell design for extremely low RDS(ON)
Exceptional on-resistance and maximum DC current capability
Features
lSuper high density cell design for extremely low RDS(ON)
lExceptional on-resistance and maximum DC current capability
Application
lPower Management in Note book
lDC/DC Converter
lLoad Switch
lLCD Display inverter
| File Name | Title | Description |
|---|---|---|
| SL20N10 TO-252.pdf | SL20N10 TO-252 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
