Highdensity celldesign forLow Ros(on)
Voltagecontrolled smallsignal switch
Rugged andreliable
Features
● Highdensity celldesign forLow Ros(on)
● Voltagecontrolled smallsignal switch
● Rugged andreliable
● High saturation current capability
● ESD protected
Applications
● Load Switch for Portable Devices
● DC/DC Converter
| File Name | Title | Description |
|---|---|---|
| 2N7002KW SOT-323.pdf | 2N7002KW SOT-323 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
