● Trench Power LV MOSFET technology
● High Power and current handing capability
Product Summary
● VDS 20V
● ID 2.0A
● RDS(ON)( at VGS=4.5V) ＜68 mohm
● RDS(ON)( at VGS=2.5V) ＜115 mohm
General Description
● Trench Power LV MOSFET technology
● High Power and current handing capability
Applications
● PWM application
● Load switch
| File Name | Title | Description |
|---|---|---|
| SL2102 SOT-323.pdf | SL2102 SOT-323 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
