● Low input Capacitance
● Fast Switching Speed
● Low Input / Output Leakage
Product Summary
● VDS 30V
● ID 300mA
● RDS(ON)( at VGS=10V) ＜8.0ohm
● RDS(ON)( at VGS=4.5V) ＜13.0ohm
● ESD Protected Up to 2.5KV (HBM)
General Description
● Trench Power MV MOSFET technology
● Voltage controlled small signal switch
● Low input Capacitance
● Fast Switching Speed
● Low Input / Output Leakage
Applications
● Battery operated systems
● Solid-state relays
● Direct logic-level interface：TTL/CMOS
| File Name | Title | Description |
|---|---|---|
| 2SK3018W SOT-323.pdf | 2SK3018W SOT-323 | N-Channel Power MOSFET |
| SL250N04Q-PDFN56.pdf | SL250N04Q PDFN56 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| REACH.pdf | REACH | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
