● High power and current handing capability
● Lead free product is acquired
● Surface mount package
Description
The SLP240C03D uses advanced trench technology to provide excellent RDS(ON) and low gate charge . The complementary MOSFETs may be used to form a level shifted high side switch, and for a host of other applications.
Features
lN-Channel
VDS= 30V,Io =8.5A
RDS(ON) < 21mΩ @ VGS=10V
Rosow< 32mΩ @ VGS=4.5V
lP-Channel
VDS= -30V,lo= -7.0A
RDS(ON)< 45m2 @ VGS=-10V
RDS(ON)< 60mΩ @ VGS=-4.5V
lHigh power and current handing capability
lLead free product is acquired
lSurface mount package
| File Name | Title | Description |
|---|---|---|
| SLP240C03D SOP-8.pdf | SLP240C03D SOP-8 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
