● Advanced Trench Technology
● Provide Excellent RDS(ON) and Low Gate Charge
● Lead free product is acquired
● Description:
These N-channel enhancement mode power mosfets used advanced trench technology design, provided excellent Rdson and low gate charge. Which accords with the RoHS standard.
● Features:
● VDS = 30V,ID =150A
● RDS(ON)，2.8 mΩ(Typ) @ VGS =10V
● RDS(ON)，4.4mΩ(Typ) @ VGS =4.5V
● Advanced Trench Technology
● Provide Excellent RDS(ON) and Low Gate Charge
● Lead free product is acquired
● Application:
● Load Switch
● PWM Application
● Power management
| File Name | Title | Description |
|---|---|---|
| SL30N02D TO-252.pdf | SL30N02D TO-252 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
