The SL8205FC is a versatile and efficient adjustable DC-DC regulator designed to provide stable output voltage from a higher input voltage. This switching regulator is particularly suitable for applications where a high efficiency, reliable voltage conversion is required. The device is housed in a compact TO-263-5 package, making it an excellent choice for space-constrained designs.
Download datasheet Inquiry
Our advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
The SL8205FC is a versatile and efficient adjustable DC-DC regulator designed to provide stable output voltage from a higher input voltage. This switching regulator is particularly suitable for applications where a high efficiency, reliable voltage conversion is required. The device is housed in a compact TO-263-5 package, making it an excellent choice for space-constrained designs.
Features
● 95% efficiency at 1A 5V output
● Low Rds(on) for internal switches (top/bottom): 70/40mΩ
● 4.5-20V input voltage range
● Instant PWM architecture to achieve fast transient responses
● External soft start limits the inrush current
● Pseudo-constant frequency: 500kHz at heavy loads
● 5A continuous, 6A peak load current capability
● 1.5% 0.6V reference
● Output over current limit
● Output short circuit protection with current foldback
● Thermal shutdown and auto recovery
● RoHS Compliant and Halogen Free
Applications
● Automotive systems
● LCD TV
● Set Top Box
● Notebook
● Storage
● High power AP router
● Networking
