The SL6106SE is a high-efficiency 1.5MHz synchronous step down DC/DC regulator IC capable of delivering up to 1.5A output current. The device is available in an adjustable version. Supply current with no load is 40uA and drops to <1uA in shutdown. The 2.7V to 5.5V input voltage range makes the SL6106SE ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable systems. PWM/PFM mode operation provides very low output ripple voltage for noise sensitive applications.
Download datasheet Inquiry
Our advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
The SL6106SE is a high-efficiency 1.5MHz synchronous step down DC/DC regulator IC capable of delivering up to 1.5A output current. The device is available in an adjustable version. Supply current with no load is 40uA and drops to <1uA in shutdown. The 2.7V to 5.5V input voltage range makes the SL6106SE ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable systems. PWM/PFM mode operation provides very low output ripple voltage for noise sensitive applications.
Features
● Up to 1.5A Current Output
● High Efficiency: Up to 96%
● 2.7V to 5.5V Input Voltage Range
● 1.5MHz Constant Frequency Operation
● No Schottky Diode Required
● Low dropout Operation:100% Duty Cycle
● PFM Mode for High Efficiency in Light Load
● Low Quiescent Current: 40μA
● Over temperature Protected
● Short Circuit Protection
● Inrush Current Limit and Soft Start
● SOT-23-5 Package
Applications
● Cellular and Smart Phones
● Wireless and DSL Modems
● Battery-Powered Equipment
● Portable Media Player (PMP)
| File Name | Title | Description |
|---|---|---|
| SL6106SE SOT-23-5.pdf | SL6106SE SOT-23-5 | - |
