The SL8292B DC-DC Regulator is a high-performance component designed for efficient power management. It supports an input voltage range of -0.3V to 32V and an output voltage range of -0.3V to 32V, making it versatile for various applications. With a maximum output current of 3A and a switching frequency of 500kHz, this regulator ensures stable and reliable performance. It is housed in an ESOP-8 package, offering a compact and convenient form factor for integration into electronic systems.
Download datasheet Inquiry
Our advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
The SL8292B DC-DC Regulator is a high-performance component designed for efficient power management. It supports an input voltage range of -0.3V to 32V and an output voltage range of -0.3V to 32V, making it versatile for various applications. With a maximum output current of 3A and a switching frequency of 500kHz, this regulator ensures stable and reliable performance. It is housed in an ESOP-8 package, offering a compact and convenient form factor for integration into electronic systems.
Features
● Wide 4.5V to 30V Operating Input Range
● 3A Continuous Output Current
● 500KHz Switching Frequency
● Short Protection with Hiccup-Mode
● Built-in Over Current Limit
● Built-in Over Voltage Protection
● PFM Mode for High Efficiency in Light Load
● Internal Soft-Start
● 130mΩ/100mΩ Low RDS(ON) Internal Power MOSFETs
● Output Adjustable from 0.923V
● No Schottky Diode Required
● Integrated internal compensation
● Thermal Shutdown
● Available in ESOP8 Package
● -40°C to +85°C Temperature Range
Applications
● Digital Set-top Box (STB)
● Tablet Personal Computer (Pad)
● Flat-Panel Television and Monitor
● Wi-Fi Router / AP
● Digital Video Recorder (DVR)
● Portable Media Player (PMP)
● Cable Modem / XDSL
● General Purposes
| File Name | Title | Description |
|---|---|---|
| SL8292B.pdf | SL8292B | - |
