The 1SS181 is a versatile general-purpose diode designed for a wide range of electronic applications. With a forward voltage of 1.2V and a maximum reverse voltage of 85V, it is ideal for circuits requiring efficient rectification and protection against reverse polarity.
Download datasheet Inquiry
Our adventage
Description:
The 1SS181 is a versatile general-purpose diode designed for a wide range of electronic applications. With a forward voltage of 1.2V and a maximum reverse voltage of 85V, it is ideal for circuits requiring efficient rectification and protection against reverse polarity.
Features:
● High Voltage Rating: With a VRRM of 85V, the 1SS181 can handle higher voltages, making it suitable for various power supply and signal processing applications.
● Low Forward Voltage: The VF of 1.2V ensures minimal voltage drop across the diode, enhancing energy efficiency in circuit designs.
● Low Leakage Current: A low reverse leakage current (IR) of 0.5μA helps maintain circuit integrity and reliability, particularly in low-power applications.
● Compact Package: Housed in a SOT-23 package, the diode offers space-saving advantages and ease of integration into compact circuit designs.
Applications:
● Power Supply Circuits: Used for rectification and voltage regulation in power supply units.
● Signal Protection: Safeguards sensitive components from reverse voltage and voltage spikes in signal processing circuits.
● Consumer Electronics: Integrates into various consumer electronics for efficiency and reliability enhancement.
● Automotive Electronics: Suitable for automotive applications requiring robust performance and space-efficient design.
