SS16 Surface Mount Schottky Power Rectifier SMA
Download datasheet InquiryFeatures
Low profile package.
Ideal for automated placement.
Ultrafast reverse recovery time.
Low power losses,high efficiency.
Low forward voltage drop.
High surge capability.
High temperature soldering: 260C/10 seconds at terminals.
Mechanical Date
Case: JEDEC DO-214AC molded plastic body over glass passivated chip
Terminals: Solder plated,solderable per J-STD-002B and JESD22-B102D
