Trench Power MV MOSFET technology.
Voltage controlled small signal switch.
Low input Capacitance.
Features
●Trench Power MV MOSFET technology.
●Voltage controlled small signal switch.
●Low input Capacitance.
●Fast Switching Speed
●Low input / Output Leakage
Application
●Battery operated systems
●Solid-state relays
| File Name | Title | Description |
|---|---|---|
| 2N7002K SOT-23.pdf | 2N7002K SOT-23 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
