High Voltage Tolerance:suitable for high-voltage applications.
Low On-Resistance:improving overall efficiency.
Wide Operating Temperature Range:reliability in extreme conditions.
Maximum ratings( Ta=25℃ unless otherwise noted)
| Parameter | Symbol | Value | Unit |
| Drain-SourceVoltage | VDS | 60 | V |
| Gate-SourceVoltage | VGS | ±20 | |
| ContinuousDrainCurrent | ID | 3 | A |
| PulsedDiodeCurren | IDM | 10 | |
| ContinuousSource-DrainCurrent(DiodeConduction) | IS | 0.76 | |
| PowerDissipation | PD | 1.25 | W |
| File Name | Title | Description |
|---|---|---|
| SL3422.pdf | SL3422 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
