● Fast switching
● 100% avalanche tested
● Improved dv/dt capability
Description
lThis Power MOSFET is produced using advanced TRENCH technology. This advanced technology has been especially tailored to minimize conduction loss, provide superior switching performance, and withstand high energy pulse in the avalanche and commutation mode.
Features
lVDS=30V，ID=90A
lRDS（ON）TYP=4.2mΩ@VGS=10V
lRDS（ON）TYP=5.6mΩ@VGS=4.5V
lVery Low On-resistance RDS(ON)
lFast switching
l100% avalanche tested
lImproved dv/dt capability
Application
lPower Management
lPWM Application
lLoad Switch
| File Name | Title | Description |
|---|---|---|
| SL90N03R PDFN5×6-8L.pdf | SL90N03R PDFN5×6-8L | - |
