● 100% avalanche tested
● Easy to use/drive
● RoHS compliant
Description
lThis Power MOSFET is produced using advanced Trench technology. This devices provide an excellent gate charge and RDS(on), which leads to extremely communication and conduction losses. So it is very suitable for AC/DCpower conversion, load switch and industrial power applications.
Features
lVDS=30V，ID=100A
lRDS（on）Typ=2.9mΩ@VGS=10V
lRDS（on）Typ=4.8mΩ@VGS=4.5V
lLow FOM RDS(on)×Qgd
l100% avalanche tested
lEasy to use/drive
lRoHS compliant
Application
lPower Management
lPWM Application
lLoad Switch
| File Name | Title | Description |
|---|---|---|
| SL100N03R PDFN5×6-8L.pdf | SL100N03R PDFN5×6-8L | - |
