Type:N-Channel
Vdss:30V
Id:5.6A
Pd:1.2W
RDS(on)@Vgs,Id:21mΩ@10V,29A
Vgs(th)@Id:1.5V@250uA
Qg@Vgs:5.2nC@10V
Ciss@Vds:490pF@15V
Crss@Vds:68pF@15V
Working Temperature:-55℃~+150℃@(Tj)
MAXIMUM RATINGS
| Characteristic | Symbol | Max | Unit |
| Drain-SourceVoltage | BVDSS | -30 | V |
| Gate-SourceVoltage | VGS | 12 | V |
| DrainCurrent(continuous) | ID | -2.6 | A |
| DrainCurrent(pulsed) | IDM | -18 | A |
| TotalDeviceDissipation | PD | 1000 | mW |
| TA=25℃ | |||
| Junction | TJ | 150 | ℃ |
| StorageTemperature | Tstg | -55to+150 | ℃ |
| File Name | Title | Description |
|---|---|---|
| SL3405.pdf | SL3405 | - |
