● Very low on-resistance RDS(ON)
● Low Gate Charge
● Excellent Gate Charge x RDS(ON) Product
General Description
● Very low on-resistance RDS(ON)
● Low Gate Charge
● Excellent Gate Charge x RDS(ON) Product
Applications
● High Frequency Switching and Synchronous Rectification
Product Summary
● VDS 40V
● ID 130A
● RDS(ON) (at VGS =10V) < 1.7mΩ
● RDS(ON) (at VGS =4.5V) < 2.4mΩ
100% DVDS Tested
100% UIS Tested
100% Rg Tested
| File Name | Title | Description |
|---|---|---|
| SL130N04Q.pdf | SL130N04Q | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
