● Very low level gate drive requirements allowing direct operation in 3V circuits. Vas(h) < 1.5V.
● Gate-Source Zener for ESD ruggedness >6ky Human Body Model
● Replace multiple NPN digital transistors with one DMOSFET.
Features
l0.22 A, 25 V. RDS(ON) =4 Ω @ VGS = 4.5 V
RDS(ON) = 5Ω @ VGS = 2.7 V.
lVery low level gate drive requirements allowing direct operation in 3V circuits. Vas(h) < 1.5V.
lGate-Source Zener for ESD ruggedness >6ky Human Body Model
lReplace multiple NPN digital transistors with one DMOSFET.
| File Name | Title | Description |
|---|---|---|
| FDV301N SOT-23.pdf | FDV301N SOT-23 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
