The Polar Bidirectional TVS Diode is a robust semiconductor device designed to protect sensitive electronic circuits from transient voltage events in both directions. It efficiently clamps excessive voltage levels, safeguarding against potential damage and ensuring the reliability of electronic systems.
Download datasheet InquiryOur advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
The Polar Bidirectional TVS Diode is a robust semiconductor device designed to protect sensitive electronic circuits from transient voltage events in both directions. It efficiently clamps excessive voltage levels, safeguarding against potential damage and ensuring the reliability of electronic systems.
Features
● Glass Passivated Die Construction
● Uni- and Bi-Directional Versions Available
● Excellent Clamping Capability
● Fast Response Time
● Plastic Material: UL Flammability Classification Rating 94V-0
Mechanical Data
● Case: SMB/DO-214AA, Molded Plastic
● Terminals: Solder Plated, Solderable per MIL-STD-750, Method 2026
● Polarity: Cathode Band or Cathode Notch
● Marking: Type Number
● Weight: 0.093 grams (approx.)
Applications
● Telecommunications
● Automotive Electronics
● Industrial Electronics
● Consumer Electronics
| File Name | Title | Description |
|---|---|---|
| SMBJ18CA.pdf | SMBJ18CA | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
?The Polar Bidirectional TVS Diode is a high-performance semiconductor device designed to protect sensitive electronic circuits from transient voltage events in both directions. It effectively clamps excessive voltage levels and dissipates surge currents, ensuring the reliability and longevity of electronic systems.
SMBJ20CA TVS Diode DO-214AA
SMBJ7.0A TVS Diode DO-214AA
Vrwm:9.4V VBR(min):10.5V VBR(max):11.6V Ir:5μA VC:15.6V Ppp@10/1000μs:600W
PD: 3000mW VZ(Nom) @ IZT: 12V VZ(Min) @ IZT: - VZ(Max.) @ IZT: - ZZT @ IZT: 6.5Ω IR @VR: 1.0µA Package:DO-214AA
PD: 3000mW VZ(Nom) @ IZT: 15V VZ(Min) @ IZT: - VZ(Max.) @ IZT: - ZZT @ IZT: 9.0Ω IR @VR: 1µA Package: DO-214AA
VRWM (max): 13V VBR(min): 14.4V VBR(max): 15.9V IR(max): 5µA VC(max): 21.5V Package: SMA
This high-power TVS (Transient Voltage Suppression) Diode, featuring a color-banded cathode for easy identification, is designed to offer superior protection against transient voltage spikes. With its high breakdown and clamping voltages, this diode is ideal for safeguarding sensitive electronics in demanding applications.
