SMBJ36CA Surface Mount Transient Voltage Suppessor Diode SMB

Our advantages

Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.

Description
The Polar Bidirectional TVS Diode is a sophisticated electronic component designed to safeguard sensitive circuits from transient voltage spikes and surges. With a VRWM (Working Peak Reverse Voltage) of 36V and VBR (Breakdown Voltage) ranging from 40V to 46V, this diode provides robust protection against overvoltage events. It features an ultra-low reverse leakage current of 5μA, ensuring minimal power dissipation and high efficiency during normal operation. The diode can handle surge currents up to 10.3A (Ipp@10/1000μs) and effectively clamps transient voltages with a VC (Clamping Voltage) of 58.1V.

Features

● Glass Passivated Die Construction

● Uni-and Bi-Directional Versions Available

● Excellent Clamping Capability

● Fast Response Time

● Plastic Material: UL Flammability Classification Rating 94V-0

Mechanical Data

● Case:SMB/DO-214AA,Molded Plastic

● Terminals:Solder Plated,Solderable per MIL-STD-750, Method 2026

● Polarity:Cathode Band or Cathode Notch

● Marking:Type Number

● Weight: 0.093 grams (approx.)

Applications

Telecommunication Systems
Industrial Electronics
Automotive Electronics
Consumer Electronics
