The Polar Bidirectional TVS (Transient Voltage Suppression) Diode is a specialized semiconductor device designed to protect sensitive electronic circuits from transient voltage spikes and surges. This compact diode ensures bidirectional clamping, effectively shielding connected components from voltage fluctuations in both directions. Its robust design and high-performance specifications make it an ideal choice for applications requiring reliable overvoltage protection.
Download datasheet InquiryOur advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
The Polar Bidirectional TVS (Transient Voltage Suppression) Diode is a specialized semiconductor device designed to protect sensitive electronic circuits from transient voltage spikes and surges. This compact diode ensures bidirectional clamping, effectively shielding connected components from voltage fluctuations in both directions. Its robust design and high-performance specifications make it an ideal choice for applications requiring reliable overvoltage protection.
FEATURES
● Glass Passivated Die Construction
● Uni- and Bi-Directional Versions Available
● Excellent Clamping Capability
● Fast Response Time
● Plastic Case Material has UL Flammability Classification Rating 94V-O
MECHANICAL DATA
● Case : JEDEC SMA(DO-214AC), Transfer Molded Epoxy
● Terminals : Solder Plated, Solderable per MIL-STD-750, Method 2026
● Polarity : Cathode Band Except Bi-Directional
Applications
● Consumer Electronics
● Telecommunications
● Automotive Electronics
● Industrial Equipment
| File Name | Title | Description |
|---|---|---|
| SMAJ6.5CA.pdf | SMAJ6.5CA | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
The Polar Unidirectional TVS Diode is a specialized semiconductor device designed to protect sensitive electronic circuits from transient voltage events. With its precise specifications and robust design, it provides effective voltage clamping and transient suppression, ensuring the reliability of electronic systems.
SMAJ10CA Transient Voltage Suppressor DO-214AC
SMAJ28CA Transient Voltage Suppressor DO-214AC
Vrwm:10.2V VBR(min):11.4V VBR(max):12.6V Ir:5μA VC:16.7V Ppp@10/1000μs:600W
This high-power TVS (Transient Voltage Suppression) Diode, featuring a color-banded cathode for straightforward identification, is engineered to deliver robust protection against high-energy voltage spikes. Its advanced design ensures effective clamping and suppression in circuits requiring high transient energy handling.
● SLE0504/SLE0503 are surge rated diode arrays designed to protect high speed data interfaces. This series has been specifically designed to protect sensitive components which are connected to data and transmission lines from overvoltage caused by ESD (electrostatic discharge), CDE (Cable Discharge Events), and EFT (electrical fast transients). ● The unique design incorporates surge rated, low capacitance steering diodes and a TVS diode in a single package. During transient conditions, the steering diodes direct the transient to either the positive side of the power supply line or to ground. The internal TVS diode prevents over-voltage on the power line, protecting any downstream components. ● The low capacitance array configuration allows the user to protect four high-speed data or transmission lines. The low inductance construction minimizes voltage overshoot during high current surges.
?The Polar Bidirectional TVS Diode is a high-performance semiconductor device designed to protect sensitive electronic circuits from transient voltage events in both directions. It effectively clamps excessive voltage levels and dissipates surge currents, ensuring the reliability and longevity of electronic systems.
The Polar Bidirectional TVS (Transient Voltage Suppression) Diode is a versatile semiconductor device engineered to protect electronic circuits from transient voltage events. It features bidirectional clamping capabilities, meaning it can protect against positive and negative voltage spikes, ensuring robust protection in both directions.
