This high-power TVS (Transient Voltage Suppression) Diode is engineered to provide superior protection against voltage spikes and transients. It features a color-banded cathode for easy installation and ensures reliable performance in a range of electronic applications.
Download datasheet InquiryOur advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
This high-power TVS (Transient Voltage Suppression) Diode is engineered to provide superior protection against voltage spikes and transients. It features a color-banded cathode for easy installation and ensures reliable performance in a range of electronic applications.
Features
● Transient protection for high-speed data lines
● IEC 61000-4-2 (ESD) ±30kV (Contact)
±30kV (Air)
● Peak power dissipation: 4800W (8/20μs)
● Working voltages : 4.5V
● Low leakage current
● Low clamping voltage
● Ultra-small package (2.0mm×2.0mm×0.5mm)
● Solid-state silicon-avalanche technology
Applications
● Power supply protection
● Personal digital assistants (PDA's)
● Microprocessors based equipment
● Power Management
● Cell phone Handsets and Accessories
● Portable Electronics
● Peripherals
| File Name | Title | Description |
|---|---|---|
| SLESD5311N-2TR.PDF | SLESD5311N-2TR | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
