Alternative equivalent for LITEON LTV-M601 | Slkor SLM601 Optocoupler
Download datasheet Inquiry
Our advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Slkor alternative equivalents to LITEON.
| LITEON | Slkor Replacements | ||
| Part Number | Part Number | Product Category | Package |
| LTV-M601 | SLM601 | Optocoupler | SOP-5 |
10Mbit/s High Speed Logic Gate Photo Coupler
Description
The SLM601 consists of a high efficient AlGaAs Light Emitting Diode and a high speed optical detector with SOP5 package.The operating parameters are guaranteed over the tempterature range of - 55°C to 100°C. It can reach 10Mbit/s and is a high-speed logic gate optocoupler.
Features
● High isolation 3750 VRMS
● DC input with logic gate output
● Operating temperature range - 55 °C to
100 °C
● REACH compliance
● Halogen free
● MSL class free
Applications
● Ground loop elimination
● LSTTL to TTL, LSTTL or CMOS
● Line receiver, data transmission
● Data multiplexing
● Switching power supply
● Pulse transformer replacement
| File Name | Title | Description |
|---|---|---|
| SLM601 SOP-5.PDF | SLM601 SOP-5 | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
SL3H7X is composed of phototransistors, optically coupled to gallium arsenide infrared light-emitting diodes, packaged in SSOP4 as a very small and thin coupler.
The SL0601 optocouplers consists of an 850nm AlGaAS LED,optically coupled to a very high speedintegrated photo?detector logic gate that quickly outputs.This device is housed in an 8-pin standard package, conforming to the standard package outline.
The 6N135/ 6N136 consists of a high efficient AlGaAs Light Emitting Diode and a high speed optical detector. This design provides excellent AC and DC isolation between the input and output sides of the Optocoupler.Connection for the bias of the photodiode improves the speed that of a conventional phototransistor coupler by reducing the base-collector capacitances. The internal shield ensureshigh common mode transient immunity. A guaranteed common mode transient immunityis up to 1KV
