High density cell design for ultra low Rdson
Good stability and uniformity with high EAs
Excellent package for good heat dissipation
General Features
● VDS =60V. ID =17A
RDS(ON)<73 mΩ VGS=10V
RDS(ON)<88 mΩ@VGS=4.5V
● Improved dv/dt capability
● High density cell design for ultra low Rdson
● Good stability and uniformity with high EAs
● Excellent package for good heat dissipation
Applications
● Power switching application
● Hard switched and high frequency circuits
● Motor drive
| File Name | Title | Description |
|---|---|---|
| SL17N06DN1.pdf | SL17N06DN1 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
