The SL6206 series is a CMOS step-down voltage regulator characterized by high ripple suppression, low powerconsumption, low dropout, and features such as overcurrent and short-circuit protection.
● These devices exhibit very low quiescent current (70μA typical) and are capable of delivering 300mA output current with minimal input-to-output voltage differentials, while maintaining excellent regulation.
● Due to their minimal voltage drop and quiescent current, these devices are particularly suitable for batterypowered products aimed at extending battery life, such as computers, consumer electronics, and industrial equipment.
Our advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Descriptions
● The SL6206 series is a CMOS step-down voltage regulator characterized by high ripple suppression, low powerconsumption, low dropout, and features such as overcurrent and short-circuit protection.
● These devices exhibit very low quiescent current (70μA typical) and are capable of delivering 300mA output current with minimal input-to-output voltage differentials, while maintaining excellent regulation.
● Due to their minimal voltage drop and quiescent current, these devices are particularly suitable for batterypowered products aimed at extending battery life, such as computers, consumer electronics, and industrial equipment.
Features
● Output rang: 1.2V - 3.6V
● 300mA output current
● High PSRR: 70 dB at 1 kHz
● Extremely low quiescent current: 70μA (typical)
● Less than 1μA in shutdown mode
● Junction temperature operation is -40°C to +85°C
Applications
● CDMA/GSM mobile phones
● PDAs, MP3
● WLAN and Bluetooth devices
● Cordless phone
● Battery powered system
