The 78MXX series of three-terminal package with several fixed output voltages making it useful in a wide range of applications.
Download datasheet InquiryDescription
The 78MXX series of three-terminal package with several fixed output voltages making it useful in a wide range of applications.
Features
● Output Current up to 1A
● Output Voltages of 5V
● Thermal Overload Protection
● Short Circuit Protection
● Output Transistor Safe Operating Area (SOA)Protection
Applications
● Electronic Point-of-Sale
● Medical and Health Fitness Applications
● Printers
● Appliances and White Goods
● TVs and Set-Top Boxes
| File Name | Title | Description |
|---|---|---|
| 78M05.pdf | 78M05 | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
The 78MXXA series of three-terminal package with several fixed output voltages making it useful in a wide range of applications.
SL4284 is a NPN type monolithic integrated fixed voltage regulator in a 3-pin TO package, with a typical drive current of 400mA, and the chip package TO252-3. The chip is applied to driving of micro-processor systems or automobile applications of several conditions; in addition, it has such as overloading protection, short circuit protection and over-temperature protection.If the input voltage V1 is within the ranges of (VQ+Vdr)﹤V1﹤55V, it is regulated to VQ, and the voltage difference Vdr changes between 0.3V and 0.5V according to the size of the driving current.
The SL4275 is a monolithically integrated low-dropout fixed voltage regulator in a 5-pin TO package. Input voltages up to 55V are regulated to an output voltage VQ of 5.0V. The chip can drive 450mA load and has short circuit protection and over temperature protection. When the output voltage VQ is lower than the typical value of 4.65V, the RQ pin of the chip will generate a low-level reset signal, and the reset delay time can be set by the D pin delay capacitor.
SL42764 is a monolithic integrated low dropout voltage regulator, with load current as high as 400mA. With the ranges for input voltage of 5V-42V, it can provide output voltage with accuracy ranges of ±2%. The device is designed for application schemes for automobiles in severe environments. It is equipped with the overload, short circuit protection and overheating protection functions. SL42764 is also applicable to all the other application schemes in need of a stable voltage during 2.5V to 20V. With extremely low quiescent current, SL42764 is specially designed for applications in VBAT for a long term. In addition, when the cut-off of the device enables the input pin, the cut-off current is smaller than 10μA.
