●Fast switching
●100% avalanche tested
●Improved dv/dt capability
Description
lThis Power MOSFET is produced using advanced TRENCH technology. This advanced technology has been especially tailored to minimize conduction loss, provide superior switching performance, and withstand high energy pulse in the avalanche and commutation mode.
Features
lVDS= 30V，ID=90A
lRDS（ON）TYP = 3.6mΩ @ VGS =10V
lRDS（ON）TYP = 5.3mΩ @VGS =4.5V
lVery Low On-resistance RDS(ON)
lLow Crss
lFast switching
l100% avalanche tested
lImproved dv/dt capability
Application
lPortable Equipment and Battery Powered systems
lPower Management in Notebook Computer
| File Name | Title | Description |
|---|---|---|
| SL90P03G PDFN3X3-8L.pdf | SL90P03G PDFN3X3-8L | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
