● Trench Power LV MOSFET technology
● High Power and current handing capability
Product Summary
● VDS 20V
● ID 0.75A
● RDS(ON)( at VGS=4.5V) ＜350 mohm
● RDS(ON)( at VGS=2.5V) ＜500 mohm
● ESD Protected Up to 3.0KV (HBM)
General Description
● Trench Power LV MOSFET technology
● High Power and current handing capability
Applications
● Load/Power Switching
● Interfacing Switching
● Logic Level Shift
| File Name | Title | Description |
|---|---|---|
| SL3134K SOT-523.pdf | SL3134K SOT-523 | - |
| Proposition-65-Compliance-Report_1.pdf | Proposition 65 Compliance Report_1 | - |
| Proposition-65-Compliance-Report_2.pdf | Proposition 65 Compliance Report_2 | - |
| REACH.pdf | REACH | - |
| RoHS-1.pdf | RoHS | - |
