Type: N-Channel
Vdss: 60V
Id: 5A
RDS(on)@Vgs,Id: 120mΩ@20V,5A
Vgs(th)@Id: 1V@250μA
Pd: 1.2W
Description
lTrench Power MV MOSFET technology.
lExcellent package for heat dissipation.
lHigh density cell design for low RDS(ON).
Applications
lDC/DC Converters
lPower management functions
| File Name | Title | Description |
|---|---|---|
| SL05N06A SOT-223.pdf | SL05N06A SOT-223 | - |
