Universal Diode
Download datasheet InquiryLow coat construction.
Low forward voltage drop.
Low reverse leakage.
High forward surge current capability.
High temperature soldering guaranteed: 260C/10 secods/.375" (9.5mm) lead length at 5 Ibs (2.3kg) tension.
Mechanical Data
Case: Transfer molded plastic.
Epoxy: UL94V-O rate flame retardant.
Polarity: Color band denotes cathode end.
Lead: Plated axial lead, solderable per MIL-STD-202E method 208C.
Mounting position: Any.
Maximum Ratings And Electrical Characteristics
Ratings at 25 C ambient temperature unless otherwise specified.
Single Phase, half wave, 60Hz, resistive or inductive load.
For capacitive load derate current by 20%.
| File Name | Title | Description |
|---|---|---|
| M7.pdf | M7 | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
VZTyp- Precision- PD:500mW Ir:100nA@12V
VZTyp- Precision- PD:500mW Ir:100nA@13V
VZTyp- Precision- PD:500mW Ir:100nA@11V
VZTyp- Precision- PD:500mW Ir:100nA@9.1V
VZTyp- Precision- PD:500mW Ir:100nA@7.5V
VZTyp- Precision- PD:500mW Ir:100nA@8.2V
PD: 500mW Vznom: 20V IZT: 5mA VZT(Min): 19.52V VZT(Max.): 20.391V ZZT(Max.): 85Ω (IZT=5mA) IR(Max.): 0.1μA (VR=15V) Package: SOD-123
PD: 500mW Vznom: 6.8V IZT: 5mA VZT(Min): 6.65V VZT(Max.): 6.93V ZZT(Max.): 40Ω (IZT=5mA) IR(Max.): 0.5μA (VR=3.5V) Package: SOD-123
