The SL9062 (dual), and SL 9064 (quad) are dual and quad low voltage (1.5V to 5.5V) operational amplifiers (opamps) with rail-to-rail input and output swing capabilities. These devices are very suitable for applications where low voltage operation, a small footprint, and high capacitive load drive are required. SL9062S and SL9064S are with Shutdown function.
Download datasheet Inquiry
Our advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.
Description
The SL9062 (dual), and SL 9064 (quad) are dual and quad low voltage (1.5V to 5.5V) operational amplifiers (opamps) with rail-to-rail input and output swing capabilities. These devices are very suitable for applications where low voltage operation, a small footprint, and high capacitive load drive are required. SL9062S and SL9064S are with Shutdown function.
Features
● Excellent THD+N 100dB
● Excellent SNR 110dB
● Rail-to-rail input and output
● Low input offset voltage: ±0.5mV typ
● Unity-gain bandwidth: 25MHz
● Low quiescent current (per opamp): 400μA typ
● Operational at supply voltages as low as 1.5V
● Easier to stabilize with higher capacitive load due to resistive open-loop output impedance
● Shutdown function (SL9062S and SL9064S)
Applications
● Infotainment system
● HVAC: heating, ventilating, and air conditioning
● Motor control
● Wearable devices
● Sensor signal conditioning
● Power modules
● Active filters
