According to the "Wuxi Daily" report, on October 7, 19 major integrated circuit projects settled in Wuxi, with a total investment of30.34 billion includingBasic Semiconductors and 2 third-generation semiconductor projects of Jingzhan Semiconductor. cba28e740861436f3c92dd169a5208f6

Basic Semiconductors:

Headquarters project contract

According to reports, the basic semiconductor contract constructionVehicle grade The third-generation semiconductor R&D and manufacturing headquarters project.
"Three Generations and a Half Wind Direction" previously reported that the project is under construction and is expected to be put into operation by the end of 2021, and will enter mass production in mid-2022.
098d80cf6c726c5d493632d3f7b950f5

In addition to this project, Basic Semiconductor has 3 production lines under construction: ▲Nanjing Pukou The manufacturing base has started construction in March 2020 and is expected to be connected by the end of 2021. Process development and manufacturing of SiC epitaxial wafers; ▲Co-built by Yizhuang, Beijing6-inch silicon carbide wafer production line will achieve mass production in the fourth quarter of this year; ▲The third-generation semiconductor industry base in Shenzhen Pingshan has started construction at the end of 2020 and is expected to be put into production in 2023, with an annual production capacity will reach2 million SiC devices.

Crystal Semiconductor:

GaN epitaxy project settled

At the same time, Jingzhan Semiconductor'sGallium nitride epitaxial materials R&D and industrialization projects were also signed and settled in Wuxi. Specific project information is yet to be announced. In addition to this project, in March 2021, Suzhou Industrial Park also announced the "Environmental Assessment Document for Jingzhan Semiconductor's New Gallium Nitride Epitaxial Wafer Production and Expansion Project". The project intends to invest250 million yuan, with an annual output of GaN epitaxial wafers after completion500,000 pieces . 2605cbf62d6ddaf4ee28665ea4a4d329

According to Jingzhan's official website, at the end of 2014, Jingzhan took the lead in releasing commercial 8-inch silicon-based nitride for the first time in the world Gallium epitaxial wafer products. Up to now, Jingzhan has completed the A+ round of financing to expand the production scale. The monthly production capacity of 150mm GaN-on-Si epitaxial wafers reaches10,000 pieces . At present, Jingzhan has more than 150 well-known semiconductor companies and research institute customers around the world. And not long ago, Jingzhan Semiconductor also showed a 12-inch, 1200V silicon-based GaN epitaxial wafer, which is the most suitable for the use of mainstream12-inch CMOS production line paved the way for GaN HEMT transistors.

8fbdf69e2c7862865accf691fecb9e22

Disclaimer: This article is reproduced from "The Third Generation Semiconductor Trend". This article only represents the author's personal views, not the views of Sac Micro and the industry, and is only for reprinting and sharing , support the protection of intellectual property rights, please indicate the original source and author for reprinting, if there is any infringement, please contact us to delete it.
